Tube4Audio: 2012

866A RCA

Mercury Vapor Rectifier
Vf = 2,5V
If = 5A

6P3P

Beam Power

Base	Octal (Int.Octal, IO) K8A, USA 1935
Filament	Vf 6.3 Volts / If: 0.9 Ampere / -: Indirect / -: Parallel, (AC/DC) /
Description	Chinese equivalent for 6L6. Glass tubular bulb.

5Z4 RCA metal

Full-Wave Vacuum Rectifier
Octal Base
Vf = 5V
If = 2A

6RA9

Single Triode
mirip dengan ECC, tetapi hanya single triode

1H5 GT RCA

Direct Heat Tride

Base	Octal (Int.Octal, IO) K8A, USA 1935 (Codex=Up)
Filament	Vf 1.4 Volts / If: 0.05 Ampere / -: Direct / -: Battery = /
Description	Glass octal type used as combined detector and amplifier in battery-operated receivers. Filament 1.4 volts, 0.05 amperes. Characteristics of triode unit as class A amplifier. Diode is located at negative end of filament.

http://www.radiomuseum.org/tubes/tube_1h5gt.html

EF 86

EF86 is often found in ancient Radio (vintage tube radio),

is easy to find from the tube the other (except modern tube).

Most assemblers are used for Preamp tube amps and the input of a tube amp.

Ampli Tabung 6N3 (6L6) Single Ended

Just take advantage of Used Goods For Ampli Tube
Transformer former Philips Radio
OT former Grundig Tape Roll
6N3 former radio transmitter All Bands
Own use aluminum chassis bending 1.2 mm
Rectifier 6u5 russia
all still in good condition ...
for starters sound quite satisfying .... cost is quite cheap

Standard components:

Ampli tabung 6V6 PushPull

6V6 tube amps use a common market, using the topology (schematic) push pull common as well and are often found on the Internet.
specs:
OT = China
Transformer = American
Transformer Coke = local
Chassis = China
Power tube = 6n6c russia (6V6)
Inverter tube = ecc 81 sylvania black plate
input tube = ecc 83 black plate

Point to point soldering

6F6 RCA

Power Pentode
Octal Base
Uf=6,3V
If=0,7A

6F6, KT63 Power Pentode. Octal base version of type 42. Moderate power output rating—9 watts max. (single-ended Class A circuit); 11 watts max. (push-pull Class A circuit); 19 watts max. (push-pull Class AB₂ circuit). Available in metal (numbered "6F6"), shouldered glass ("6F6-G"), and cylindrical glass ("6F6-GT"). Sometimes used as a transformer-coupled audio driver for types 6L6-GC and 807 when those tubes were used in Class AB₂ or Class B amplifiers. Also used as a Class C oscillator/amplifier in transmitters.

6L6G SYLVANIA

Beam Power Audio Amplifier.
Including fan favorites audio tube which is rarely available in the market. maybe most people just stored / collected ....
obtained by the author with NOS condition ..

http://www.hifitubes.nl/weblog/index.php/sylvania-6l6g-datasheet/

6L6, EL37 High-powered beam tetrode. There are several variations. Except for types 6L6-GC and 6L6-GX, all have the same maximum output ratings—11.5 watts (single-ended Class A circuit); 14.5 watts (push-pull Class A circuit); 34 watts (push-pull Class AB₁; 60 watts (push-pull Class AB₂ circuit). Types 6L6 and 25L6 were introduced in 1935 as the first beam tetrodes. Both types were branded with the L6 ending to signify their (then) uniqueness among audio output tubes. However, this is the only similarity between the two tubes. (Type 6W6-GT is the 6.3 volt heater version of types 25L6-GT and 50L6-GT.)

6L6 (metal envelope) and 6L6-G (shouldered glass envelope) were used in pre-World War II radios and Public Address amplifiers.
6L6-GA Post-war version of type 6L6-G, in smaller ST-14 shape.
6L6-GB Post-war improved version in a cylindrical glass envelope. Similar to type 5881.
6L6-WGB "Industrial" version of type 6L6-GB.
6L6-GC Final and highest-powered audio version of the tube. Max. outputs—32 watts (single-ended Class A circuit); 17.5 watts (push-pull Class A circuit); 55 watts (push-pull Class AB₁ circuit); 60 watts (push-pull Class AB₂ circuit)
6L6-GX Class C oscillator/amplifier used in transmitters. Max. output—30 watts. (All versions may be used as a Class C oscillator/amplifier, but this version is specifically designed for this purpose, has a special ceramic base.)

EL156 Telefunken

here's only one, can not be tried,

so want to hear ... but the socket was hard to come by ..

PreAmp 6SN7

Preamp 6SN7 dengan asesoris EM84

bisa diganti dengan 6SL7

872A RCA

872A ini juga termasuk
Mercury Vapor rectifier
http://www.radiomuseum.org/tubes/tube_872a.html
872A A Mercury Vapor Diode with a peak inverse voltage of 10Kv and peak anode current of 5 amperes. Average anode current, 1250mA, forward drop, 10 volts. Heater voltage, 5.0 at 6.25A. Base fits R.C.A. UT-541A Socket.

ECC 88 SIEMEN

Gold Pin

866 A ULTRON

http://en.wikipedia.org/wiki/866A

866 A Mercury Vapor Diode with a peak inverse voltage of 5Kv and peak anode current of 1 ampere. Average anode current, 250mA, forward drop, 15 volts. Heater voltage and current, 2.5 at 5A. American 4-Pin(UX) base.
